一、安装 kubeadm=1.22.1-00 kubelet=1.22.1-00 kubectl=1.22.1-00
根据互联网区的k8s主机上安装的组件和版本，离线部署到内网区中：
在纯净主机上执行：
查看需要的所有组件
apt-get install –dry-run -qq kubeadm=1.22.1-00 kubelet=1.22.1-00 kubectl=1.22.1-00 | grep “Inst” | awk -F'[ (]+’ ‘{print $2}’
conntrack
cri-tools
ebtables
kubernetes-cni
socat
kubelet
kubectl
kubeadm
在已安装kube软件的主机执行：
查看组件的版本
dpkg -l | grep -E ‘conntrack|cri-tools|ebtables|kubernetes-cni|socat|kubelet|kubectl|kubeadm’ | awk ‘{print $2 “=” $3}’
conntrack=1:1.4.5-2
cri-tools=1.25.0-00
ebtables=2.0.11-3build1
kubeadm=1.22.1-00
kubectl=1.22.1-00
kubelet=1.22.1-00
kubernetes-cni=1.1.1-00
libnetfilter-conntrack3:amd64=1.0.7-2
socat=1.7.3.3-2
下载组件
【手工方式】：
dpkg -l | grep -E ‘conntrack|cri-tools|ebtables|kubernetes-cni|socat|kubelet|kubectl|kubeadm’ | awk ‘{print “apt-get download -qq ” $2 “=” $3}’ > kube.sh
root@master-3:/data/pkg# cat kube.sh ( bash kube.sh )
apt-get download -qq conntrack=1:1.4.5-2
apt-get download -qq cri-tools=1.25.0-00
apt-get download -qq ebtables=2.0.11-3build1
apt-get download -qq kubeadm=1.22.1-00
apt-get download -qq kubectl=1.22.1-00
apt-get download -qq kubelet=1.22.1-00
apt-get download -qq kubernetes-cni=1.1.1-00
apt-get download -qq libnetfilter-conntrack3:amd64=1.0.7-2
apt-get download -qq socat=1.7.3.3-2
【脚本方式】：
vim pkgs.txt
conntrack
cri-tools
ebtables
kubernetes-cni
socat
kubelet
kubectl
kubeadm
vim download_pkgs.sh
#!/bin/bash
# 指定组件列表文件路径
components_file="$(pwd)/pkgs.txt"
# 检查文件是否存在
if [ ! -f "$components_file" ]; then
echo "Error: Components file not found."
exit 1
fi
# 临时目录用于存放下载的组件
temp_dir="temp_dir"
mkdir $temp_dir
cd $temp_dir
# 读取组件列表文件中的每个组件，并执行下载命令
while read -r component; do
version=$(dpkg -l | grep -E "^ii\s+$component\s" | awk '{print $3}')
echo "Checking component: $component"
echo "Checking version: $version"
if [ -n "$version" ]; then
echo "Downloading $component=$version..."
apt-get download -qq --allow-unauthenticated "$component=$version"
else
echo "Component $component not found."
fi
done < "$components_file"
cd - > /dev/null
# 打包下载的组件
tar -czvf downloaded_components.tar.gz -C "$temp_dir" .
# 删除临时目录
rm -rf "$temp_dir"
echo "Downloaded components are packed and saved as downloaded_components.tar.gz"
把下载好的所有组件传到内网服务器，进行离线安装：
dpkg -i *.deb
二、准备和安装 kubernetes 所需的相关镜像
[root@master1 ~]#kubeadm config images list –kubernetes-version=v1.22.1
k8s.gcr.io/kube-apiserver:v1.22.1
k8s.gcr.io/kube-controller-manager:v1.22.1
k8s.gcr.io/kube-scheduler:v1.22.1
k8s.gcr.io/kube-proxy:v1.22.1
k8s.gcr.io/pause:3.5
k8s.gcr.io/etcd:3.5.0-0
k8s.gcr.io/coredns/coredns:v1.8.4
把互联网区的服务器上的镜像导出，并导入到内网服务器
root@master-1:/data/kube_images# docker images
REPOSITORY TAG IMAGE ID CREATED SIZE
registry.cn-hangzhou.aliyuncs.com/google_containers/kube-apiserver v1.22.1 f30469a2491a 2 years ago 128MB
registry.cn-hangzhou.aliyuncs.com/google_containers/kube-scheduler v1.22.1 aca5ededae9c 2 years ago 52.7MB
registry.cn-hangzhou.aliyuncs.com/google_containers/kube-proxy v1.22.1 36c4ebbc9d97 2 years ago 104MB
registry.cn-hangzhou.aliyuncs.com/google_containers/kube-controller-manager v1.22.1 6e002eb89a88 2 years ago 122MB
registry.cn-hangzhou.aliyuncs.com/google_containers/etcd 3.5.0-0 004811815584 2 years ago 295MB
registry.cn-hangzhou.aliyuncs.com/google_containers/coredns v1.8.4 8d147537fb7d 2 years ago 47.6MB
registry.cn-hangzhou.aliyuncs.com/google_containers/pause 3.5 ed210e3e4a5b 2 years ago 683kB导出镜像
docker save -o kube-apiserver.tar f30469a2491a
docker save -o kube-scheduler.tar aca5ededae9c
docker save -o kube-proxy.tar 36c4ebbc9d97
docker save -o kube-controller-manager.tar 6e002eb89a88
docker save -o etcd.tar 004811815584
docker save -o coredns.tar 8d147537fb7d
docker save -o pause.tar ed210e3e4a5b
打包镜像：
tar cf kube_images.tar -C kube_images/ .
将kube_images.tar 传到内网服务器，并解压，安装。
导入镜像：
docker load -i kube-apiserver.tar
批量导入：
mkdir kube_images
tar xf kube_images.tar -C kube_images
cd kube_images
for i in ./*.tar ; do docker load -i “$i”;done
给镜像打标签：
vim im_tag.txt
registry.cn-hangzhou.aliyuncs.com/google_containers/kube-apiserver v1.22.1 f30469a2491a 2 years ago 128MB
registry.cn-hangzhou.aliyuncs.com/google_containers/kube-scheduler v1.22.1 aca5ededae9c 2 years ago 52.7MB
registry.cn-hangzhou.aliyuncs.com/google_containers/kube-proxy v1.22.1 36c4ebbc9d97 2 years ago 104MB
registry.cn-hangzhou.aliyuncs.com/google_containers/kube-controller-manager v1.22.1 6e002eb89a88 2 years ago 122MB
registry.cn-hangzhou.aliyuncs.com/google_containers/etcd 3.5.0-0 004811815584 2 years ago 295MB
registry.cn-hangzhou.aliyuncs.com/google_containers/coredns v1.8.4 8d147537fb7d 2 years ago 47.6MB
registry.cn-hangzhou.aliyuncs.com/google_containers/pause 3.5 ed210e3e4a5b 2 years ago 683kB
vim docker_tag.sh
#!/bin/bash
# 从im_tag.txt文件中读取镜像信息到数组images
mapfile -t images < im_tag.txt
# 循环遍历数组中的每个元素
for image_info in "${images[@]}"; do
# 使用awk分割每个元素，第1列是目标标签，第3列是源镜像ID
target_image_name=$(echo "${image_info}" | awk '{print $1}')
target_image_version=$(echo "${image_info}" | awk '{print $2}')
target_image_tag=${target_image_name}:${target_image_version}
source_image_id=$(echo "${image_info}" | awk '{print $3}')
# 使用docker tag命令为源镜像ID添加目标标签
docker tag "${source_image_id}" "${target_image_tag}"
echo "已为镜像 ${source_image_id} 添加标签 ${target_image_tag}"
done
echo "标签添加完成"
脚本注释：
mapfile 命令从 im_tag.txt 文件中读取行并将它们存储在名为 images 的数组中。 -t 选项表示删除行尾的换行符。
${images[@]} 当中的 @ 表示展开数组的语法。在Bash中，@ 用于将数组中的元素展开为一个由空格分隔的列表，每个元素作为一个独立的项。具体来说， ${images[@]} 会将数组 images 中的所有元素分别展开，并用空格分隔它们，每个元素作为一个独立的项，这使得你可以像处理普通的空格分隔字符串一样处理数组的元素。例如，如果数组 images 包含以下元素： images=(“image1” “image2” “image3″)， ${images[@]} 将会展开成以下形式：”image1” “image2” “image3″，
这使得你可以在循环、赋值等上下文中方便地处理数组中的每个元素，就好像它们是单独的字符串。在很多情况下，${images[@]} 可以用来遍历数组，执行操作，或者将数组中的元素传递给命令等。
三、部署kube集群：
在第一个 master 节点运行 kubeadm init 初始化命令
kubeadm init –control-plane-endpoint k8s.zspt.com –kubernetes-version=v1.22.1 –pod-network-cidr 172.17.0.0/16 –service-cidr 10.10.0.0/16 –service-dns-domain zspt.com –image-repository registry.cn-hangzhou.aliyuncs.com/google_containers –token-ttl=0
Your Kubernetes control-plane has initialized successfully!
To start using your cluster, you need to run the following as a regular user:
mkdir -p $HOME/.kube
sudo cp -i /etc/kubernetes/admin.conf $HOME/.kube/config
sudo chown $(id -u):$(id -g) $HOME/.kube/config
Alternatively, if you are the root user, you can run:
export KUBECONFIG=/etc/kubernetes/admin.conf
You should now deploy a pod network to the cluster.
Run "kubectl apply -f [podnetwork].yaml" with one of the options listed at:
https://kubernetes.io/docs/concepts/cluster-administration/addons/
You can now join any number of control-plane nodes by copying certificate authorities
and service account keys on each node and then running the following as root:
kubeadm join k8s.zspt.com:6443 --token wesgr0.h5vieh75mn87zqzk \
--discovery-token-ca-cert-hash sha256:aa1b7329732dc2f5bf890e6e7fe186a6d71a5dd1a58054902320c97234f4e6df \
--control-plane
Then you can join any number of worker nodes by running the following on each as root:
kubeadm join k8s.zspt.com:6443 --token wesgr0.h5vieh75mn87zqzk \
--discovery-token-ca-cert-hash sha256:aa1b7329732dc2f5bf890e6e7fe186a6d71a5dd1a58054902320c97234f4e6df
其他master节点加入集群：
1、在第一个master节点执行：
root@k8s-master-1:/opt# kubeadm init phase upload-certs –upload-certs
W1206 18:24:24.000876 750987 version.go:103] could not fetch a Kubernetes version from the internet: unable to get URL “https://dl.k8s.io/release/stable-1.txt“: Get “https://dl.k8s.io/release/stable-1.txt“: context deadline exceeded (Client.Timeout exceeded while awaiting headers)
W1206 18:24:24.001012 750987 version.go:104] falling back to the local client version: v1.22.1
[upload-certs] Storing the certificates in Secret “kubeadm-certs” in the “kube-system” Namespace
[upload-certs] Using certificate key:
f2979ead43a09c4363ba7bc8c1e24eec1d007d682763db0eedda5a223e10af92
2、在其他master节点执行命令，加入集群：
结合初始化成功后提示的命令： kubeadm join命令和kubeadm init 产生的结果拼接起来
kubeadm join k8s.zspt.com:6443 –token wesgr0.h5vieh75mn87zqzk \
–discovery-token-ca-cert-hash sha256:aa1b7329732dc2f5bf890e6e7fe186a6d71a5dd1a58054902320c97234f4e6df \
–control-plane –certificate-key f2979ead43a09c4363ba7bc8c1e24eec1d007d682763db0eedda5a223e10af92
执行结果：
This node has joined the cluster and a new control plane instance was created:
* Certificate signing request was sent to apiserver and approval was received.
* The Kubelet was informed of the new secure connection details.
* Control plane (master) label and taint were applied to the new node.
* The Kubernetes control plane instances scaled up.
* A new etcd member was added to the local/stacked etcd cluster.
To start administering your cluster from this node, you need to run the following as a regular user:
mkdir -p $HOME/.kube
sudo cp -i /etc/kubernetes/admin.conf $HOME/.kube/config
sudo chown $(id -u):$(id -g) $HOME/.kube/config
Run ‘kubectl get nodes’ to see this node join the cluster.
3、查看结果：
root@k8s-master-1:/opt# kubectl get node
NAME STATUS ROLES AGE VERSION
k8s-master-1.zspt.com NotReady control-plane,master 26m v1.22.1
k8s-master-2.zspt.com NotReady control-plane,master 3m37s v1.22.1
k8s-master-3.zspt.com NotReady control-plane,master 25s v1.22.1
安装cilium网络插件
在其中一个master节点运行：
curl -LO https://github.com/cilium/cilium-cli/releases/download/v0.15.12/cilium-linux-amd64.tar.gz
tar xf cilium-linux-amd64.tar.gz
mv cilium /usr/local/bin/cilium
#使用默认的隧道模式，以及VXLAN协议，但自定义了地址分配模式和PodCIDR
cilium install \
--set kubeProxyReplacement=strict \
--set ipam.mode=kubernetes \
--set ipam.operator.clusterPoolIPv4PodCIDRList=172.17.0.0/16 \
--set ipam.Operator.ClusterPoolIPv4MaskSize=24
# 功能同上，但明确指明了路由模式和使用的协议，将vxlan换成geneve即可换用隧道协议
cilium install \
--set kubeProxyReplacement=strict \
--set ipam.mode=kubernetes \
--set routingMode=tunnel \
--set tunnelProtocol=vxlan \
--set ipam.operator.clusterPoolIPv4PodCIDRList=172.17.0.0/16 \
--set ipam.Operator.ClusterPoolIPv4MaskSize=2
# 使用原生路由（native routing）模式，
cilium install \
--set kubeProxyReplacement=strict \
--set ipam.mode=kubernetes \
--set routingMode=native \
--set ipam.operator.clusterPoolIPv4PodCIDRList=172.17.0.0/16 \
--set ipam.Operator.ClusterPoolIPv4MaskSize=24 \
--set ipv4NativeRoutingCIDR=172.17.0.0/16 \
--set autoDirectNodeRoutes=true
安装cilium及hubble及prometheus插件
cilium install \
--set kubeProxyReplacement=strict \
--set ipam.mode=kubernetes \
--set routingMode=native \
--set ipam.operator.clusterPoolIPv4PodCIDRList=172.17.0.0/16 \
--set ipam.Operator.ClusterPoolIPv4MaskSize=24 \
--set ipv4NativeRoutingCIDR=172.17.0.0/16 \
--set hubble.relay.enabled="true" \
--set autoDirectNodeRoutes=true \
--set prometheus.enabled=true \
--set operator.prometheus.enabled=true \
--set hubble.enabled="true" \
--set hubble.metrics.enableOpenMetrics=true \
--set hubble.ui.enabled="true" \
--set hubble.relay.enabled="true" \
--set hubble.metrics.enabled="{dns,drop,tcp,flow,port-distribution,icmp,httpV2:exemplars=true;labelsContext=source_ip\,source_namespace\,source_workload\,destination_ip\,destination_namespace\,destination_workload\,traffic_direction}"
禁用kube-proxy
kubectl edit ds kube-proxy -n kube-system
# Please edit the object below. Lines beginning with a '#' will be ignored,
# and an empty file will abort the edit. If an error occurs while saving this file will be
# reopened with the relevant failures.
#
# daemonsets.apps "kube-proxy" was not valid:
# * spec.template.metadata.labels: Invalid value: map[string]string{"k8s-app":"kube-proxy111"}: `selector` does not match template `labels`
# * spec.template.metadata.labels: Invalid value: map[string]string{"k8s-app":"kube-proxy111"}: `selector` does not match template `labels`
# * spec.selector: Invalid value: v1.LabelSelector{MatchLabels:map[string]string{"k8s-app":"kube-proxy222"}, MatchExpressions:[]v1.LabelSelectorRequirement(nil)}: field is immutable
#
apiVersion: apps/v1
kind: DaemonSet
metadata:
annotations:
deprecated.daemonset.template.generation: "1"
creationTimestamp: "2023-12-06T10:06:52Z"
generation: 1
labels:
k8s-app: kube-proxy
name: kube-proxy
namespace: kube-system
resourceVersion: "6503058"
uid: 62ab2752-74eb-47f6-ae56-ef44fff48b72
spec:
revisionHistoryLimit: 10
selector:
matchLabels:
k8s-app: kube-proxy
template:
metadata:
creationTimestamp: null
labels:
k8s-app: kube-proxy
spec:
containers:
- command:
- /usr/local/bin/kube-proxy
- --config=/var/lib/kube-proxy/config.conf
- --hostname-override=$(NODE_NAME)
env:
- name: NODE_NAME
valueFrom:
fieldRef:
apiVersion: v1
fieldPath: spec.nodeName
image: registry.cn-hangzhou.aliyuncs.com/google_containers/kube-proxy:v1.22.1
imagePullPolicy: IfNotPresent
name: kube-proxy
resources: {}
securityContext:
privileged: true
terminationMessagePath: /dev/termination-log
terminationMessagePolicy: File
volumeMounts:
- mountPath: /var/lib/kube-proxy
name: kube-proxy
- mountPath: /run/xtables.lock
name: xtables-lock
- mountPath: /lib/modules
name: lib-modules
readOnly: true
dnsPolicy: ClusterFirst
hostNetwork: true
nodeSelector:
kubernetes.io/os: linux #改为linux 111
priorityClassName: system-node-critical
restartPolicy: Always
schedulerName: default-scheduler
securityContext: {}
serviceAccount: kube-proxy
serviceAccountName: kube-proxy
terminationGracePeriodSeconds: 30
tolerations:
- operator: Exists
volumes:
- configMap:
defaultMode: 420
name: kube-proxy
name: kube-proxy
- hostPath:
path: /run/xtables.lock
type: FileOrCreate
name: xtables-lock
- hostPath:
path: /lib/modules
type: ""
name: lib-modules
updateStrategy:
rollingUpdate:
maxSurge: 0
maxUnavailable: 1
type: RollingUpdate
status:
currentNumberScheduled: 6
desiredNumberScheduled: 6
numberAvailable: 6
numberMisscheduled: 0
numberReady: 6
observedGeneration: 1
updatedNumberScheduled: 6
测试
kubectl create deploy demoapp –image=ikubernetes/demoapp:v1.0 –replicas=3
kubectl create service nodeport demoapp –tcp=80:80
